Description
|
Features: Miniature size, high power density Universal AC input / full range Miniature size, high power density Top international brand components for key parts UL, CE approved (refer to spec. of each series)t Protections: overload/ over voltage/ short circuit 5 years limited warranty Dimensions: 199 x 98 x 39(mm) Specification: |
|
|
AC input voltage range |
85~264VAC |
|
Input frequency |
47~63Hz |
|
Inrush current |
cold start, 20A/115V, 40A/230V |
|
Input leakage current |
๏ผ1mA/ 230VAC |
|
Line regulation (full load) |
≤±0.5% |
|
Output voltage adjust range |
±10% |
|
Output overload protection |
105~130%, shut off, re-power on to recover |
|
Output over voltage protection |
115~150%, shut off, re-power on to recover |
|
Withstand voltage |
I/P -O/P: 3.0KVAC/1min I/P -F/G: 1.5KVAC/1min O/P-F/G: 0.5KVAC/1min |
|
Rise time |
50ms@full load (typical) |
|
Hold up time |
20ms@full load (typical) |
|
Operating temperature |
-20โ~+70โ (refer to the derating curve) |
|
Safety standards |
meets GB4943, UL60950, EN60950 |
|
EMC standards |
meets GB9254, EN55022 classB, EN55024 EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11 |
|
Cooling method |
convection |
|
Packing |
0.66kg/pcs, 28pcs/CTN |
